PME Test Plug Male Female 2" 3" FIG602 FIG1502 FIG2202 Blanking Plug NPT Port (1/2" 9/16")

 lug Union Male & Female

2" FIG 1502 Female Blind and Male Blind are crucial components in high-pressure piping systems, particularly within the oil and gas industry.

These specialized hammer union parts serve a critical function: to safely and securely cap off or isolate sections of a pipeline, valve, or manifold.

They are essential for maintenance, pressure testing, and temporary shutdowns, ensuring system integrity and operator safety under extreme conditions.

Crafted from high-strength forged alloy steel, these fittings are engineered to withstand the demanding environments of oilfield operations.

The "2 inch" designation refers to the nominal bore size, while "FIG 1502" indicates the specific design and pressure rating, typically up to 15,000 PSI cold working pressure.

The 2" FIG 1502 Male Blind, also known as a hammer union blanking plug, features a male sub connection and is often equipped with a wing nut for fast and easy installation without specialized tools.

The 2" FIG 1502 Female Blind, or blind nut, provides a female threaded connection to seal off a male end.

Both types of blind plugs are vital for maintaining a pressure-tight, leak-proof seal in applications like hydraulic fracturing, cementing, and well testing.

For sour gas environments, these components are also available in NACE MR0175 compliant materials, offering enhanced resistance to sulfide stress cracking and corrosion.

Whether you need a standard 2" FIG 1502 hammer union blind plug or a sour service blind cap, these heavy-duty fittings are engineered for reliability and long-term performance in the harshest conditions.

Integral Cross Pup Joint Adapter 2 Inch FIG602 for Middle East Compatible with FMC Chiksan and SPM

PME Integral Flowlines are engineered with a 2” nominal size and 6000 Psi working pressure, featuring FIG602 Male x Female union connections. These components are designed to meet the standards and extreme conditions of the Middle East market.



Our comprehensive product line offers versatile solutions for high-pressure well servicing, including fracturing, cementing, and well-testing applications, compatible with FMC Chiksan and SPM.



1. Integral Pup Joints (2” FIG602)

Available in lengths of 1 Meter, 3 Meters, and up to 10 Feet, our PME 2-inch pup joints are perfect for extending flowlines and serving as critical parts of cementing and circulating hose loops.

Material: Forged from premium alloy steel.

Process: Optimized heat-treatment for maximum durability.

Application: Ideal for fracturing and transporting high-pressure fluids.



2. Integral Cross (2” FIG602 FxMxMxM)

Designed for multi-line manifold integration, our Chiksan-style crosses provide a robust four-way connection.

Configuration: 2” 6000 Psi with FIG602 MxMxMxF ends.

Usage: Specifically built for fracturing manifolds and high-pressure well testing lines.



3. Integral Adapters & Crossovers

Standard Size: 2” FIG602 Female x 1-1/4” 602 Male.

Function: Enables transitions between different connection sizes or flange unions.

Optional Size:

2” 1502 Male x 1-1/4" 602 Female

2” 602 Male x 2” 1502 Female

3” 1502 Female x 2” 1502 Male



Technical Comparison: Cross vs. Crossover

Integral Cross: Functions as a four-way connection within a manifold system, allowing for the distribution of high-pressure fluid across multiple lines.

Crossover: Acts as a bridge, enabling the transition between mismatched connection types, sizes, or pressure ratings, completing the Chiksan flowline assembly.



Why Choose PME Integral Flowline Series?

Manufactured to API 6A and API 16C standards.

Forged from high-grade alloy steel with heat-treated components to withstand corrosive and high-stress environments.

FIG602 MxF union design allows for rapid installation and removal, reducing downtime and operational costs.



Contact our technical team today for a quote or to discuss custom configurations for your Middle East operations.



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

2 Inch FIG602 6000 PSI Flowline Fittings for Middle East Operations

In the demanding of oilfield operation, Chiksan flowlines, specifically designed with 2” nominal size, 6000 Psi working pressure, along with 2” FIG602 Male x Female union connections, are designed to meet need of the Middle East Market.



Low Torque Plug Valves: PME valves feature high-grade seals and replaceable inserts, ensuring long-term durability and shutoff.



Long Sweep Swivel Joint Style 10: PME Swivel Joint Style 10 for drilling utilizes a long-sweep design to minimize erosio. It provides the necessary flexibility to compensate for vibration.



Integral Forged Construction: PME integral flowline components for oil & gas are forged from high grade alloy steel



FIG602 Hammer Unions: Featuring precision-machined threads to ensure rapid make-up and a secure, pressure-tight fit during high pressure pumping.



Feature	Specification
Description	Flowlines 2" (Integral Flowline)
Union Connection	FIG602 Hammer Union 6000 PSI
Nominal Size	2-inch
Working Pressure	6,000 PSI
Swivel Configuration	Long Sweep Swivel Joint Style 10
Valve Type	Low Torque Plug Valve
Material	Forged Alloy Steel



Applications

PME Flowlines 2" FIG602 is the API standard for integral flowline connections for oil drilling operations, purpose-built for:

Oil & Gas Drilling: Managing high-pressure mud circulation and blowout preventer (BOP) lines.

Hydraulic Fracturing (Fracking): Handling abrasive fluids and the pressure of frac sites.

Well Testing & Completion: Providing temporary for high-pressure wellbore fluids.

Acidizing & Cementing: Resisting chemical erosion while maintaining a consistent 6000 PSI working pressure flowline rating.



To upgrade your flowline system? Contact PME Team today to request a formal quote of Flowlines 2". Our experts are standing by to help you select the right configuration for your specific drilling environment.



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

2026-01-04

3 Inch Figure 1502 Test Cap NACE Rated Wing Thread Caps NPT Port for Sour Service

PME 3" Figure 1502 Wing and Thread Test Caps are engineered for well testing and drilling manifolds. These blind caps feature an integrated 1/2" NPT port.



Whether you are conducting hydrostatic testing or sealing off a line in a sour gas environment, PME1502 caps deliver the reliability required for the world’s most demanding oilfields.



Key Features for 3 Inch Figure 1502 Test Cap NACE Rated

10000 PSI Working Pressure: Rated for 10K CWP during high-pressure well testing.

NACE MR0175 Compliance: Manufactured from forged alloy steel, making them ideal for H2S (sour gas) environments.

Interchangeability: Compatible with standard Figure 1502 hammer union components from major global manufacturers.



Global Brand Comparison

PME Figure 1502 Test Caps are designed to meet the performance standards set by international industry leaders such as FMC (TechnipFMC), SPM (Caterpillar), and Weir.

Compatibility: Our test caps wing and thread are interchangeable with FMC WECO 1502 components, ensuring a perfect fit with your existing fleet.

Availability: While major brands often face long lead times, we maintain a fast production optimized for rapid deployment to the USA (Permian/Eagle Ford), Middle East (Saudi Aramco/ADNOC projects), and North Sea operations.



Frequently Asked Questions (FAQ)

Q: Can these caps be used for permanent installations?

A: While designed primarily as "Test Blind Caps" for temporary sealing and pressure monitoring during drilling and well testing, NACE-rated construction allows for use in any 1502-compatible system where a blind end with a port is required.



Q: What is the benefit of the 1/2" NPT port?

A: The port allows to attach a pressure gauge to monitor the line status in real-time.



Feature	3" 1502 Wing Cap	3" 1502 Thread Cap
Nominal Size	3 Inch	3 Inch
Union Type	Figure 1502	Figure 1502
Connection Type	Wing Nut Side	Threaded Side
Port Size	1/2" NPT	1/2" NPT
Pressure Rating	10,000 PSI CWP	10,000 PSI CWP
Test Pressure	15,000 PSI	15,000 PSI
Material Standard	Forged Alloy Steel	Forged Alloy Steel
Compliance	NACE MR0175 (Sour Service)	NACE MR0175 (Sour Service)



Secure Your High-Pressure Assets Today

Don't compromise on wellsite safety. Contact our technical sales team for a quote on NACE-certified 3" 1502 Wing and Thread caps.



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

High Pressure API 7K Cementing Hose 10000 PSI with Spiral Wrap and Safety Clamps





PME offers API 7K Cementing Hoses designed to serve as a high performance flexible connection for drilling and well servicing jobs. Our hoses are the preferred choice for operators in the UAE and international markets who prioritize durability and operational safety.



PME 10000 PSI High Pressure Hose is built to withstand the hydraulic demands of cementing operations. Rated for 10K pressure, the 2 Inch FIG1502 Cementing Hose ensures a leak-proof, secure connection (M x F) that maintains integrity. While providing 12-meter assemblies as client demand, PME can supply customized lengths up to a maximum of 30 meters to meet specific rig configurations.



Advanced Protection: Spiral Wrap Hose Protectors



One of the biggest challenges in the field is external damage. How do you protect high-pressure cementing hoses from abrasion? PME integrates Spiral Wrap Hose Protectors as a standard value-add. This external protection delivers durability, making PME Hose with Spiral Wrap Protector ideal for tough working conditions.



Extreme Abrasion Resistance: Prevents outer cover wear caused by dragging and vibration.

Extended Service Life: Reduces the frequency of replacements, lowering your total cost of ownership.

Impact Protection: Guards the hose carcass against accidental mechanical impacts on the drill floor.



Operational Safety: Safety Clamps & Hose Lifters

Application: To move cementing hoses more conveniently and securely, PME supplies Safety Clamp Hose Lifter (also known as lifting eyes)

Secure Handling: The Oilfield Safety Clamp Hose Lifter ensures the hose remains stable and balanced during lifting operations.

Enhanced Safety: Prevents accidental slips or drops, meeting the safety standards of the oil and gas sector.



Feature	Specification Details
Standard	API 7K (Drill and Well Servicing Equipment)
Hose Type	Drilling Fluid Rubber Hose / Cementing Hose
Size	2” FIG1502 M x F (Hammer Union Connection)
Pressure Rating	10,000 PSI (10K) Working Pressure
Length	12 Meters (Max. available up to 30 Meters)
Protective Accessories	Spiral Wrap Hose Protectors
Handling Accessories	Safety Clamps / Hose Lifter Eyes



Why Choose PME API 7K Hoses?

Serving the oil and gas sector for years, PME is a trusted partner for premium pressure-rated solutions. Whether you are operating in the UAE or offshore rigs globally, our API 7K Cementing Hoses provide the flexible connection you need with the safety features you demand.



Get a Quote Today

Ensure your drilling operations stay on schedule with PME’s reliable high-pressure solutions.



Contact PME for further technical information or a commercial quote for our 2” FIG1502 cementing hoses!



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

PME 3 Inch FIG 100 Welded Hammer Unions for Global Oilfield Services

PME 3" FIG 100 Welded Hammer Unions are engineered to provide the leak-proof connection for low-to-medium pressure applications.



Designed for the standards of North America, the Middle East, and Southeast Asia, PME FIG100 hammer unions represent the standard in integral piping components.



Key Features of PME 3" FIG 100 Welded Design

Butt-Weld Ends: Engineered for integration into manifold systems, ensuring a weld that matches the strength of the pipe.

Standard Pressure Rating: Rated for 1,000 PSI CWP (Cold Working Pressure), making it ideal for water, oil, and gas service.

Construction: Forged from alloy steel to withstand the mechanical stresses of drilling rig.

Rapid Assembly: Three-lug nut design allows for quick makeup and breakout using only a hammer, reducing downtime during site setup.



PME FIG 100 Welded Unions for Fluid Handling in Several Key Oil and Gas Sectors

Drilling Rigs: Used in mud suction lines, water transfer systems, and low-pressure fluid circuits.

High Pressure Manifolds: Integral parts of cementing and fracturing manifold assemblies where "welded-in" security is preferred over threaded hammer unions.

Oilfield Service Equipment: Found on truck-mounted tanks and piping systems that require frequent relocation and connections.



Whether you are operating in the Permian Basin, the deserts of the Middle East, or the offshore rigs of Southeast Asia, Contact PME team today for technical specifications, material certifications, or to request a quote for bulk orders.



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

API 16D Fire Resistant Coflex Hose 5000 PSI 1 Inch to 2 Inch

Our API 16D Fire Resistant Hose, widely known in the industry as Coflex Hose, is engineered to be the lifeline of your Blowout Preventer (BOP) control system.



PME Fire Resistant Coflex Hoses are engineered specifically for BOP (Blowout Preventer) and Diverter equipment control systems.



Our SS armored hoses are inspected and certified according to API 16D, ensuring they meet fire-resistance standards in the oilfield.



Featuring Stainless Steel (SS) Armored exterior, PME hoses are designed to handle crude oil, water, and gas under standard service conditions.



Key Features of PME Coflex Hose

API 17D Compliance: Tested to meet the standards for fire-resistant control lines in well-control equipment.

High-Pressure Reliability: Rated for a steady 5000 PSI working pressure

Versatile End Connections: Available with NPT Male fittings or Hammer Union ends (FIG602) for rapid and secure installation.



Technical Specifications



Specification	Details
Product Name	Fire Resistant Hose (Coflex Hose)
Standard Compliance	API Spec 16D
Available Sizes (ID)	1”, 1-1/2”, 2”
Working Pressure	5000 PSI
End Connections	NPT Male / FIG602 Union Ends
Max Continuous Length	Up to 100 FT
Primary Application	BOP Control Lines / Hydraulic Control Systems
Temperature Rating	Fire resistant as per API 16D requirements



Ready to upgrade your rig’s safety profile with API 16D compliant hoses? PME team is standing by to provide you with a detailed quote and shipping timelines.



PME Sales Team

Tel: +86 21 5837 2350

Cell/WhatsApp: +86 138 1899 0736

Email: contact@pmeindustrial.com

Site: www.pmeindustrial.com

Certified FIG1502 Flowline Equipment Pup Joints Swivel Joints integral Fittings

PME is the HP flowlines manufacturer in China. We produce and export quality treating irons. PME 2” FIG1502 flowlines components are designed for high pressure discharge lines, fracking manifolds, and well-testing operations, cementing and acidizing, these fittings ensure seamless flow control under the oilfield conditions.



Key Features

Designed for a Cold Working Pressure (CWP) of 15,000 PSI

Forged from high-strength alloy steel with heat treatment

Compliant with API 6A and API 16C standards

Available in NACE MR0175 standards for sour gas environments

PME adapters and tees feature a one-piece integral construction



Material List

Integral Pup Joints, 2" FIG 1502 Male x Female, CWP 15000 Psi, Length 5ft, 8ft, 10ft

Swivel Joints, 2" FIG 1502 Male x Female, Style 50, CWP 15000 Psi

Integral Adapters, 2" FIG 1502 Male x Male, Female x Female, CWP 15000 Psi

Integral Tee, 2" FIG 1502 Female x Female x Male, CWP 15000 Psi



Product Specifications

Product Name	Size & Connection	Technical Configuration	Available Options
FIG1502 Pup Joint	2" Hammer Union	Seamless Pipe / Integral	5ft, 8ft, 10ft Lengths
Swivel Joint	2" FIG1502 M x F	Style 50 (Three Planes of Rotation)	Long Sweep Design
Integral Adapter	2" FIG1502	Male x Male (M x M)	15,000 PSI CWP
Integral Tee	2" FIG1502	Female x Female x Male (F x F x M)	One-piece Forged



PME flowlines scope covers quantity check, visual check, dimension check as PME manufacturing flowlines drawings, pressure test reports, heat treatmenting reports, hardness and impact result, NDT test report, calibration certification etc.



PME have strict quality control system to ensure the quality and traceability for oilfield equipment supply. Contact PME Team for 2” FIG1502 flowline equipment. 15,000 PSI Pup Joints, Style 50 Swivels, and Integral Tees. API 6A & NACE compliant.
